ZTE FTGK 48-Port P2P Gigabit Ethernet Interface Board

ZTE FTGK Service Board Is high-density P2P Ethernet interface card and this board provides 48 P2P optical interfaces of 100 Mbps / 1000 Mbps, with a configurable speed. There are four MPO connectors on its panel. And each connector powers 12 P2P optical interfaces. MPO connectors are connected to replaceable optical modules through a fibre optic patch cord ZXA10 C300 is an optical access platform, developed with mass optical access roll-out as well as the economy in mind. Its powerful functions and high performance make mass FTTx roll-out easier than ever before.

Передняя панель:

FTGK Service Board Product Features:

Chassis Configuration (21”)
Total 23 slots
16 slots for universal line cards
2 slots for switch & control cards
2 slots for power cards
2 slots for uplink and cascading interfaces
1 slot for environment detecting card
Chassis Configuration (19”)
Total 21 slots
14 slots for universal line cards
2 slots for switch& control cards
2 slots for power cards
2 slots for uplink and cascading interfaces
1 slot for environment detecting card
Subscriber Card Density
GPON card: 8/16 ports per card
P2P card: 24/48 ports per card
XG PON1 card: 8 ports per card
Uplink interface card
4*10GE uplink per card
2*10GE+2*GE uplink per card
4*GE uplink per card
1*STM-4/OC12 or 2*STM-1/OC3 TDM uplink per card
32* E1/T1 uplink card ( balanced and unbalanced)
Environment detecting card
2 * Hz/Bit external clock interfaces
5 * Environment detecting interfaces
